CAD Support

2D CAD systems:

Most of the calculations allow direct output to major 2D CAD systems. Just choose your CAD system in the calculation and select the desired view (a projection type). A drawing is then saved directly in the CAD system with the correct scale and system of layers.

Supported CAD systems at this time: DXF file, AutoCAD, AutoCAD LT, IntelliCAD, Ashlar Graphite, TurboCAD, BricsCAD, ZWCAD, ProgeCAD....

Note: The design is fully open; you can connect other CAD systems or define new drawing templates based on the calculated values.

3D CAD systems:

These are supported by a form of independent installation that includes, in addition to calculations, the respective parametric models and interface between Excel and the respective 3D CAD system. An assembly may consist of not only individual components but also groups of components (sub-assemblies). For example, you can insert one complete solution of a belt gear at once, which is fully associative, and the dimensions of the inserted component (sub-assembly) will change automatically in case you make changes to the calculation parameters later.

Supported CAD systems:

Autodesk Inventor
(ver.: 5.3, 6.0, 7.0, 8.0, 9.0, 10.0, 11.0, 2008... 2019 ...)
SolidWorks
(ver.: 2001 Plus; 2003; 2004, 2005, 2006, 2007, 2008... 2019 ...)
Solid Edge
(ver.: 15, 16, 17, 18, 19, ... ST10 ... and next)
Creo (Pro/ENGINEER) (Details: COGRAS spol. s r.o.)
